ST 52 Pipe, ST 52 Seamless/ Welded Pipe manufacturer, Check Dimension of ST52 Welded Pipe, ST 52 D Honed Tube, ST 52 Rectangular Pipe exporter in India

ST52 Hot Finished Seamless Pipe Stockists in India, ST 52 Pipe Exporter, ST52 Seamless Hydraulic Pipe, Mild Steel ST52 Pipe Supplier in Mumbai.

It is well-known for its high-quality ST52 Seamless Pipe which is manufactured and exported by Solitaire Overseas. The dimensions and ST52 Seamless Pipe specifications of these pipes are uniquely designed for customer satisfaction. High strength, reliability, superior finish, and affordability are among the great features of the Carbon Steel ST52 Seamless Pipe. Carbon steel seamless tubes ST52 are used primarily in heavy engineering and other industrial applications.

The ST52 Seamless Pipe we supply is made using raw materials of the highest grade and modern technology. Carbon steel piping in ST52 form works effectively and runs for a long time, requiring little maintenance. These ST52 Seamless Pipes are offered at competitive prices. Welded Carbon Steel Pipes complying with DIN 2391 standards customized to client requirements. Prior to the last dispatch, Solitaire Overseas carefully inspects ST 52 welded pipes on numerous quality parameters.

DIN 2391 describes ST52 Seamless Pipe. Carbon, silicon, manganese, phosphorus, and sulfur make up the chemical composition of DIN 2391 ST52 Seamless Pipe. They are made up of strong metals that have enhanced corrosion resistance. Moreover, DIN 2391 ST52 possesses outstanding mechanical properties. The tensile strength must be at least 600 MPa, and the yield strength must be at least 520 MPa. Despite being able to elongate by a minimum of 14%, ST52 Seamless Pipe is easy to work with. Custom lengths of up to 6000mm are available in single random, double random, and custom patterns. ST52 Carbon Steel Pipe is produced with a carbon concentration of above 0.30%. Both cold- and hot-rolling techniques can be used in the production of these pipes. The ST52 Seamless Pipe is widely used in oil and gas refineries, food processing, chemical industries, boiler systems, dairy and fluid pipelines, hydraulic systems, and so on. We are the leading ST52 Seamless Pipes in Mumbai. Our goal is to supply high-quality products at the most reasonable rates.

The ST52 Seamless Pipe is produced with the help of a billet to create a hollow shell. ST52 Seamless Pipe is extremely strong and doesn’t require welding or seam to join them together. The 1.0570 Steel Smls Pipe can be easily bent or flanged and can easily withstand extreme pressures and temperatures. These pipes are available with an outer diameter of 1/2NB to 60NB. The ST52 Seamless Pipe is a mild carbon steel tube, which is extremely reliable and easy to operate. These tubes possess a smooth surface. They have a long service life and are easy to clean and maintain. DIN 1.0570 Seamless Steel Tubes is a cost-effective highly efficient pipe, which can be used in different corrosive media. ST52 Seamless Pipe is manufactured following all industry standards and is available in different shapes. Fluids over long distances are best transported and supplied using DIN 2391C circular tubes. Various structural applications can also be achieved using these tubes. Maintenance and cleaning are very straightforward. DIN 1629 ST 52 Plain-end seamless steel tubes can easily be connected to socket-weld connections or slip-on flanges. These tubes create a 90-degree angle to the tube run, which makes them an ideal option in small-diameter piping systems. The DIN 17100 ST 52.3 Welded Tube is produced by joining pieces of steel together. These tubes are available in pipe sizes between 5 mm to 1219.2mm. ST52 NBK Steel pipes can be customized to your ST52 grade specifications, including their shapes and sizes.

The ST52 Seamless Pipe Cold Finished Tube is a low-carbon manganese tube. The tube is easy to weld, and it highly impacts resistant. In normalized form, they can withstand temperatures as low as -80 degrees Celsius. A high degree of ductility is the primary characteristic of this ST52 S355 Annealed Tube. Due to their low hardness and brittleness, these tubes have good magnetic properties. Carbon concentrations in the ST52 Hydraulic Tube are lower than those in the ST52 Hydraulic Tube. Various industries use this grade due to its excellent machinability and exceptional dimensional tolerance. Precision dimensions are guaranteed with this grade. Their high hardness and excellent finish come from the abrasion resistance stones used in polishing. Extreme working pressures and temperatures can be tolerated by ST52 4 Honed Tube. Tubes from these grades come in normalized, phosphate finished and oiled on the interior and exterior. A smooth and precise finish is applied to the ST52-3 BK Honed Tube. The surface in these tubes is relieved of any stress, and the tube is annealed to give it better resistance in various applications. Our experienced staff makes use of cutting-edge technology and the best ST52 Seamless Pipe Material to produce the best products in this grade.

In spite of its wide range of applications, the precision steel tube EN 1.0570 occupies a special position among the different groups of steel tubes. By virtue of the pipe’s unique properties, these tubes are cost-effective and highly resistant to corrosion and abrasion. In addition to welded tubes, the BKA ST52 Tube is also available in electric resistance tubes. A wide range of shapes is available, including square, rectangular, circular, hydraulic, and other similar shapes. For use in commercial and domestic applications, these seamless precision steel tubes are ST52 BK DIN 2391. A range of outer diameters is available, from 4mm to 125mm. This seamless tube is produced with strict security checks and has higher tolerances than DIN 2391 ST52 BK+S. These tubes also possess good impact strength. In addition to plain, beveled, and threaded tubing ends, this DIN 2391 ST52 NBK Tube is also offered in stainless steel. The standard wire gauge in these pipes is between 10 SWG to 20 SWG. If you have any questions or would like to receive a quote for our products or the DIN 2391 St52 Pipe, please contact us.

We manufacture these Carbon Steel DIN 2391 ST52 Piping by using superior grades of high-quality raw materials and can also customize them according to the ST52 Seamless Pipe grade specifications of our internationally renowned clients. In addition to having dimensional accuracy, sturdiness, toughness, and other great properties, Carbon Steel DIN 2391 ST52 Tubing is one of the best alloys. Our ST52 DIN 2391 Carbon Steel Piping is available here in a variety of sizes and shapes depending on the client’s requirements.

ST52 Tube material properties

Standard	DIN 2391
Grade	ST52
Size	OD (4-190mm) x WT (0.5-15mm)
Outer Dimensions	4.0mm – 60.0mm
Wall Thickness	0.5mm – 8 mm
Length	max 6000mm

DIN 2391 ST52 Carbon Steel Pipes Chemical Composition

Standard	Grade	C	Si	Mn	P max	S max
DIN2391	St52	≤0.22	≤0.55	≤1.6	0.025	0.025

ST52 DIN 2391 Seamless Pipes Mechanical Properties

Cold drawn(Mandatory)		Cold drawn(Soft)		Cold Drawn and Stress Release			Anneal		Normalizing
BK1）		BKW1）		(BKS)			(GBK)1）		(NBK)1）
Grade	Tensile	Elongation	Tensile	Elongation	Tensile	Yield point	Elongation	Tensile	Elongation	Tensile	Yield point	Elongation
	N/mm2	%	N/mm2	%	N/mm2	N/mm2	%	N/mm2	%	N/mm2	N/mm2	%
St52	640	4	580	7	580	420	10	490	22	490~630	355	22

ST52 Steel Equivalent

Steel grade	Material Number
St52	1.0580

DIN 2391 ST52 Pipe Dimension Tolerance

OD Tolerance	4-30mm	31-40mm	41-50mm	51-60mm	61-70mm	71-80mm	81-90mm	91-100mm
	±0.08mm	±0.15mm	±0.20mm	±0.25mm	±0.30mm	±0.30mm	±0.40mm	±0.45mm
WT Tolerance	±10%

Other Types of DIN 2391 ST52 Carbon Steel Pipes & Tubes

DIN 2391 ST52 Pipe/Tube	DIN 2391 ST52 Seamless Pipe/Tube
Carbon Steel DIN 2391 ST52 Pipe	Carbon Steel DIN 2391 ST52 Tube Supplier
DIN 2391 ST52 Pipes Exporter	DIN 2391 ST52 High Precision Seamless Tube
DIN 2391 ST52 Seamless Pipe in Iraq	DIN 2391 ST52 Thick Wall High Precision Steel Tube
DIN 2391 ST52 Cold Drawn Carbon Seamless Steel Pipe	DIN 2391 ST52 Steel Tube Exporter
DIN 2391 Seamless Steel Precision Pipe Trader	DIN 2391 ST52 Steel Pipes Stockist
High Quality DIN 2391 ST52 Pipes in Peru	ST52 Pipes Stockist in India
DIN2391 Thin Wall Carbon Seamless Precision Steel Tube	DIN 2391 ST52 Cold Drawn Carbon Steel Pipe
EN 10305 E235 Precision Seamless Steel Tube in Malaysia	DIN 2391 EN 10305 Pipes manufacturer

Weight Chart for St52 Steel Tube Suppliers In India

Size NPS	Pipe O.D.	Wall Thickness	Pipe I.D.	Weight per Foot	Standard to XXHY	Schedule Pipe #	Section Modulus	Gallon Capacity Per Linear Foot
1/2	0.84	0.109	0.622	0.85	STD	40	.0407	.0158
0.147	0.546	1.09	XHY	80	.0478	.0122
0.188	0.464	1.31	160	.0528	.0088
0.294	0.252	1.72	XXHY	.0577	.0026
3/4	1.05	0.113	0.824	1.13	STD	40	.0705	.0277
0.154	0.742	1.48	XHY	80	.0853	.0225
0.219	0.612	1.95	160	.1006	.0153
0.308	0.434	2.44	XXHY	.1103	.0077
1	1.315	0.133	1.049	1.68	STD	40	.1328	.0449
0.179	0.957	2.17	XHY	80	.1606	.0374
0.250	0.815	2.85	160	.1904	.0271
0.358	0.599	3.66	XXHY	.2136	.0146
1 1/4	1.66	0.140	1.380	2.27	STD	40	.2346	.0777
0.191	1.278	3.00	XHY	80	.2913	.0666
0.250	1.160	3.77	160	.3421	.0549
0.382	0.896	5.22	.4110	.0328
1 1/2	1.90	0.145	1.610	2.72	STD	40	.3262	.1058
0.200	1.500	3.63	XHY	80	.4118	.0918
0.281	1.338	4.86	160	.5079	.0730
0.400	1.100	6.41	.5977	.0494
2	2.375	0.109	2.157	2.64	10	.4205	.1898
0.154	2.067	3.66	STD	40	.5606	.1743
0.218	1.939	5.03	XHY	80	.7309	.1534
0.250	1.875	5.68	.8045	.1434
0.281	1.813	6.29	.8666	.1344
0.344	1.687	7.47	160	.9806	.1161
0.436	1.503	9.04	XXHY	1.1043	.0922
2 1/2	2.875	0.120	2.635	3.53	10	.6870	.2833
0.203	2.469	5.80	STD.	40	1.0640	.2487
0.216	2.443	6.14	1.1169	.2435
0.250	2.375	7.02	1.2468	.2301
0.276	2.323	7.67	XHY	80	1.3386	.2202
0.375	2.125	10.02	160	1.6371	.1842
0.552	1.771	13.71	XXXHY	1.9971	.1280
3	3.50	0.120	3.260	4.34	1.0411	.4336
0.156	3.188	5.58	1.3122	.4147
0.172	3.156	6.12	1.4265	.4064
0.188	3.124	6.66	1.5342	.3984
0.216	3.068	7.58	STD.	40	1.7241	.3840
0.250	3.000	8.69	1.9372	.3672
0.281	2.938	9.67	2.1207	.3521
0.300	2.900	10.26	XHY	80	2.2253	.3431
0.438	2.624	14.34	160	2.8774	.2811
0.600	2.300	18.6	XXHY	3.4243	.2158
3 1/2	4.0	0.120	3.760	4.98	10	1.3776	.5768
0.226	3.548	9.12	STD.	140	2.3939	.5136
0.250	3.500	10.02	2.6001	.4998
0.281	3.438	11.17	2.8562	.4821
0.318	3.364	12.52	XHY	80	3.1400	.4617
0.636	2..728	22.87	XXHY	4.8795	.3085
4	4.5	0.120	4.260	5.62	10	1.7612	.7404
0.156	4.188	7.24	2.2354	.7156
0.188	4.124	8.67	2.6296	.6942
0.203	4.094	9.32	2.8173	.6838
0.219	4.062	10.02	3.0184	.6725
0.237	4.026	10.80	STD.	40	3.2145	.6613
0.250	4.000	11.36	3.3611	.6528
0.281	3.938	12.67	60	3.7021	.6326
0.312	3.876	13.97	4.0273	.6126
0.337	3.826	15.00	XHY	80	4.2713	.5972
0.438	3.624	19.02	120	5.1790	.5361
0.531	3.438	22.53	160	5.8997	.4822
0.674	3.152	27.57	XXHY	6.7927	.4054
5	5.563	0.188	5.187	10.80	4.1161	1.0979
0.219	5.125	12.51	4.7279	1.0716
0.258	5.047	14.63	STD.	40	5.4500	1.0391
0.281	5.001	15.87	5.8644	1.0204
0.312	4.939	17.51	6.4074	.99647
0.344	4.875	19.19	6.9358	.9696
0.375	4.813	20.80	XHY	80	7.4300	.9449
0.500	4.563	27.06	120	9.2534	.8495
0.625	4.313	32.99	160	10.7976	.7590
0.750	4.063	38.59	XXHY	12.0954	.6734
6	6.625	0.109	6.407	7.59	5	3.5769	1.6748
0.134	6.357	9.30	10	4.3475	1.6488
0.156	6.313	10.79	5.0107	1.6260
0.188	6.249	12.94	5.9351	1.5937
0.203	6.219	13.94	6.3804	1.5780
0.219	6.187	15.00	6.8261	1.5620
0.250	6.125	17.04	7.6905	1.5306
0.280	6.065	18.99	STD.	40	8.4958	1.5008
0.312	6.001	21.06	9.3416	1.4688
0.344	5.937	23.10	10.111	1.4391
0.375	5.875	25.05	10.893	1.4082
0.432	5.761	28.60	XHY	80	12.224	1.3541
0.500	5.625	32.74	13.711	1.2909
0.562	5.501	36.43	120	14.9806	1.2346
0.625	5.375	40.09	16.1821	1.1787
0.719	5.187	45.39	160	17.8243	1.0977
0.864	4.897	53.21	XXHY	20.025	.9784
1.000	4.625	60.13	21.7719	.8727
1.125	4.375	66.14	23.1237	.7809

DIN 2391 ST52 Seamless Pipe Price List
